Name: Дънна платка, ASUS PRIME H810M-A WIFI
Brand: ASUS
SKU: 90MB1KJ0-M0EAY0
Price: 129.84 EUR
Availability: InStock

☎ 0886 177 222 ✉ info@xtreme.bg

Доставка· Условия· Рекламация· Контакти·

Вход

⇆Сравни ⚙Сглоби PC Количка

ASUS

Цена

€129⁸⁴ / 253⁹⁴ лв

с ДДС

* ВЪНШЕН ДОСТАВЧИК - (1 до 3 дни)

* - Стоката е в склад на официалния вносител на марката за България. Времето за доставка е обикновено от 1 до 3 работни дни. Възможно е към момента на завършване на поръчката, продукта да е вече изчерпан. В случай на изчерпана наличност ще се свържем с Вас

К-во:

Добави в Количката

Удължи гаранцията си

+1 година: + 17€

+2 години: + 25€

Код: 90MB1KJ0-M0EAY0
Категория: Дънни Платки
Гаранция: 3 Години

РЕЙТИНГ

ТВОЯ РЕЙТИНГ

Мнения

Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.

Описание
Детайли
Мнения
ИИ Описание

Vendor_url

https://www.asus.com/motherboards-components/motherboards/prime/prime-h810m-a-wifi/

Graphics

1 x DisplayPort

1 x HDMI™ port

CPU's supported

Support Intel® Core™ Ultra Processors (Series 2) , LGA1851

Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0

Chipset

Intel® H810 Chipset

Expansion slots

Intel® Core™ Ultra Processors (Series 2)

1 x PCIe 4.0 x16 slot

Intel® H810 Chipset

1 x PCIe 4.0 x1 slot

Storage

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

Intel® H810 Chipset

M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)

4 x SATA 6Gb/s ports

Memory type

2 x DIMM slots, max. 128GB, DDR5

Supports up to 6400MT/s, Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)

Dual channel memory architecture

DIMM Fit

Supports Intel® Extreme Memory Profile (XMP) memory module

ASUS Enhanced Memory Profile II (AEMP II)

Rear panel I/O

2 x USB 10Gbps ports (2 x Type-A)

4 x USB 2.0 ports (4 x Type-A)

1 x DisplayPort

1 x HDMI™ port

1 x Wi-Fi module

1 x Intel® 1Gb Ethernet port

3 x Audio jacks

1 x PS/2 keyboard/mouse combo port

USB

Rear USB (Total 6 ports)

2 x USB 10Gbps ports (2 x Type-A)

4 x USB 2.0 ports (4 x Type-A)

Front USB (Total 5 ports)

1 x USB 5Gbps connector (supports USB Type-C®)*

1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

1 x USB 2.0 header supports 2 additional USB 2.0 ports

Connectors

Fan and Cooling Related

1 x 4-pin CPU Fan header

2 x 4-pin Chassis Fan headers

Power Related

1 x 24-pin Main Power connector

1 x 8-pin +12V CPU Power connector

Storage Related

2 x M.2 slots (Key M)

4 x SATA 6Gb/s ports

USB

1 x USB 5Gbps connector (supports USB Type-C® )

1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

1 x USB 2.0 header supports 2 additional USB 2.0 ports

Miscellaneous

3 x Addressable Gen2 headers

1 x Clear CMOS header

1 x COM Port header

1 x Front Panel Audio header (F_AUDIO)

1 x S/PDIF Out header

1 x SPI TPM header (14-1 pin)

1 x 10-1 pin Front Panel System header

Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC

- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

- Supports up to 24-Bit/192 kHz playback

Audio Features

- Audio Shielding

- Premium audio capacitors

- Dedicated audio PCB layers

Lan

1 x Intel® 1Gb Ethernet port

ASUS LANGuard

Wireless

Wi-Fi 6

1x1 Wi-Fi 6 (802.11ax)

Supports 2.4/5GHz frequency band

Bluetooth® v5.3

Bluetooth

5.3

BIOS

256 (128+128) Mb Flash ROM, UEFI AMI BIOS

Form factor

micro-ATX Form Factor 24.4 cm x 22.2 cm

Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)

Warranty

36 Months

Данни, подадени от официалния вносител за България.

Атрибут	Стойност
Vendor_url	https://www.asus.com/motherboards-components/motherboards/prime/prime-h810m-a-wifi/
Chipset	Intel® H810 Chipset
OS	Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)
Warranty	36 Months
CPU's supported	Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
CPU's supported	Support Intel® Core™ Ultra Processors (Series 2) , LGA1851
Memory type	Dual channel memory architecture
Memory type	2 x DIMM slots, max. 128GB, DDR5
Memory type	ASUS Enhanced Memory Profile II (AEMP II)
Memory type	Supports Intel® Extreme Memory Profile (XMP) memory module
Memory type	DIMM Fit
Memory type	Supports up to 6400MT/s, Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)
Form Factor	micro-ATX Form Factor 24.4 cm x 22.2 cm
Audio	- Dedicated audio PCB layers
Audio	- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
Audio	Audio Features
Audio	- Audio Shielding
Audio	- Supports up to 24-Bit/192 kHz playback
Audio	- Premium audio capacitors
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC
Rear panel I/O	3 x audio jacks
Rear panel I/O	1 x DisplayPort
Rear panel I/O	1 x HDMI™ port
Rear panel I/O	1 x PS/2 Keyboard/Mouse combo port
Rear panel I/O	4 x USB 2.0 ports (4 x Type-A)
Rear panel I/O	1 x Wi-Fi Module
Rear panel I/O	2 x USB 10Gbps ports (2 x Type-A)
Rear panel I/O	1 x Intel® 1Gb Ethernet port
LAN	ASUS LANGuard
LAN	1 x Intel® 1Gb Ethernet port
Expansion Slots	1 x PCIe 4.0 x16 slot
Expansion Slots	1 x PCIe 4.0 x1 slot
Expansion Slots	Intel® Core™ Ultra Processors (Series 2)
Expansion Slots	Intel® H810 Chipset
Wireless	Wi-Fi 6
Wireless	Supports 2.4/5GHz frequency band
Wireless	Bluetooth® v5.3
Wireless	1x1 Wi-Fi 6 (802.11ax)
Graphics	1 x HDMI™ port
Graphics	1 x DisplayPort
Features	ASUS 5X PROTECTION III
Features	ASUS Q-Design
Features	ASUS Thermal Solution
Features	- DIGI+ VRM
Features	- LANGuard
Features	- Overvoltage Protection
Features	- Stainless-Steel Back I/O
Features	- Q-DIMM
Features	- Q-LED Core
Features	- Q-Slot
Features	Aura Sync
Features	- Addressable Gen 2 headers
Features	- VRM heatsink design
Features	- SafeSlot Core+
Features	- Q-Dashboard
BIOS	256 (128+128) Mb Flash ROM, UEFI AMI BIOS
I/O	1 x DisplayPort
I/O	3 x audio jacks
I/O	1 x HDMI™ port
I/O	1 x PS/2 Keyboard/Mouse combo port
I/O	4 x USB 2.0 ports (4 x Type-A)
I/O	1 x Wi-Fi Module
I/O	2 x USB 10Gbps ports (2 x Type-A)
I/O	1 x Intel® 1Gb Ethernet port
Storage	4 x SATA 6Gb/s ports
Storage	Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
Storage	Intel® H810 Chipset
Storage	M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
Storage	M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
Bluetooth	5.3
Connectors	1 x S/PDIF Out header
Connectors	1 x COM port header
Connectors	Fan and Cooling related
Connectors	1 x 4-pin CPU Fan header
Connectors	2 x 4-pin Chassis Fan headers
Connectors	Power related
Connectors	1 x 24-pin Main Power connector
Connectors	Storage related
Connectors	4 x SATA 6Gb/s ports
Connectors	USB
Connectors	Miscellaneous
Connectors	1 x Clear CMOS header
Connectors	2 x M.2 slots (Key M)
Connectors	1 x SPI TPM header (14-1 pin)
Connectors	1 x USB 5Gbps connector (supports USB Type-C® )
Connectors	1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
Connectors	1 x Front Panel Audio header (F_AUDIO)
Connectors	1 x 8-pin +12V CPU Power connector
Connectors	1 x 10-1 pin Front Panel System header
Connectors	3 x Addressable Gen2 headers
Connectors	1 x USB 2.0 header supports 2 additional USB 2.0 ports
USB	Rear USB (Total 6 ports)
USB	4 x USB 2.0 ports (4 x Type-A)
USB	1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
USB	2 x USB 10Gbps ports (2 x Type-A)
USB	Front USB (Total 5 ports)
USB	1 x USB 2.0 header supports 2 additional USB 2.0 ports
USB	1 x USB 5Gbps connector (supports USB Type-C®)*
Тегло	0.00кг

Данни, автоматично извлечени от интернет. Точността не е гарантирана. За подробна информация, моля, свържете се с нас или посетете страницата на производителя.

Атрибут	Стойност
Сокет	LGA1851
Форм фактор	Micro-ATX
Чипсет	Intel H810
Тип памет	DDR5
Слотове за памет (count)	2
Максимална памет (GB)	64
M.2 слотове (count)	1
SATA портове (count)	4
PCIe x16 слотове (count)	1
Вграден Wi-Fi	Wi-Fi 6
Скорост на LAN	1 Gbps
USB-C портове (count)	1
RGB подсветка	Не
Тегло	0.00кг

ASUS PRIME H810M-A WIFI – Надеждна Micro-ATX дънна платка с вграден Wi-Fi

С чипсет Intel H810, ASUS PRIME H810M-A WIFI предлага стабилна производителност и основни функции за ежедневна работа. Вграденият Wi-Fi 6 осигурява бърза безжична връзка без нужда от допълнителен адаптер.

Ключови Предимства

Вграден Wi-Fi 6 – Насладете се на високоскоростна безжична мрежа за стрийминг, сърфиране и игри.
Micro-ATX форм фактор – Компактен дизайн, който се побира в по-малки кутии, без да жертва разширяемостта.
Поддръжка на DDR5 – Бъдеща технология за памет с по-бърз трансфер на данни и по-добра реакция на системата.
Разнообразни портове – USB-C, HDMI, DisplayPort и други за свързване на различни устройства.

Технически Спецификации

Спецификация	Стойност
Сокет	LGA1851
Форм фактор	Micro-ATX
Чипсет	Intel H810
Тип памет	DDR5
Слотове за памет	2
Максимална памет	64 GB
M.2 слотове	1
SATA портове	4
PCIe x16 слотове	1
Вграден Wi-Fi	Wi-Fi 6
Скорост на LAN	1 Gbps
USB-C портове	1
RGB подсветка	Не
